1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT

1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT

  • 1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT
  • 1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT
  • 1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT
  • 1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT
1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT
Product Details:
Place of Origin: Shenzhen,China
Brand Name: Neuter, OEM
Certification: CE/FCC/RoHS/TUV/UL
Model Number: SFP-100-BX20LT-A
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Get Latest Price
Packaging Details: 10 or 20PCS /Plastic tray, 1PC/Gift box
Delivery Time: Within 1-3 working days after PO confirmed
Payment Terms: T/T, Western Union, L/C
Supply Ability: 50,000pcs/Month
Contact Now
Detailed Product Description
Product Name: SFP Optical Transceiver Datarate: 155Mb/s
Wavelength: 1550TX/1310RX Transmitter: FP
Connector: LC/SC Application: OC-3/STM-1/Fast Ethernet
High Light:

cisco sfp modules

,

fiber optic sfp module


1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT







Specifications:



P/N

SFP-100-BX20LT-A

Datarate

155Mb/s

Wavelength

1550TX/1310RX

Distance

20KM

Transmitter

FP

Receiver

PIN

Media

SMF

DDM/DOM

YES

Connector

LC/SC

Application

OC-3/STM-1/Fast Ethernet

Operating Temperature

0℃~ +70℃

Voltage Supply

3.3V

Certification

CE/FCC/RoHS/TUV/UL

Brand

Neuter, OEM







100BASE-BX20-D Single mode, up to 20km, tx-1550nm, rx- 1310nm, SC



The AscentOptics Small Form-Factor Pluggable (SFP) Gigabit Interface Converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet port or slot, linking the port with the network. SFPs can be used and interchanged on a wide variety of switches and routers, can be intermixed in combinations of 1000BASE-T, 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-EX, 1000BASE-ZX, or 1000BASE-BX10-D/U on a port-by-port basis.







Applications

  • Gigabit Ethernet/Fast Ethenet
  • Fiber Channel
  • SDH/SONET/ATM
  • Switch to Switch interface
  • Router/Server interface
  • Other optical transmission systems





Competitive advantage:

1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
4. OEM/ODM  Customized label
5. Keep stock,Fast delivery





1550TX / 1310RX Alcatel Transceiver Module Single Mode 20KM SFP-100-BX20LT 0
