10G/ps Extreme SFP+ Optical Transceiver Module 1310nm 220M 10303

10G/ps Extreme SFP+ Optical Transceiver Module 1310nm 220M 10303


Specifications:




10 Gigabit Ethernet SFP+ module, 1310nm, legacy MMF 220m link, LC connector
Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a switch. Provides flexibility of interface choice .Supports "pay-as-you-populate" model. Supports digital optical monitoring capability
Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link



Features

• 10Gb/s serial optical interface compliant to 802.3aq 10GBASE-LRMM
• lectrical interface compliant to SFF-8431 specifications for enhanced 8.5 and 10 Gigabit small form factor pluggable module “SFP+”
• 1310nm FP  transmitter, PIN photo-detector
• 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface for optical transceivers
• Operating case temperature: -40 to 85 °C
• ll-metal housing for superior EMI performance
• Low power consumption
• advanced firmware allow customer system encryption information to be stored in transceiver
• Cost effective SFP+ solution, enables higher port densities and greater bandwidth
• RoHS compliant


Applications

• High-speed storage area networks
• Computer cluster cross-connect
• Custom high-speed data pipes



Extreme 10G SFP+


Competitive advantage:

1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
4. OEM/ODM  Customized label
5. Keep stock,Fast delivery
