TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet

TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet

  • TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
  • TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
  • TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
  • TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
  • TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet
Product Details:
Place of Origin: Shenzhen,China
Brand Name: AscentOptics/Neuter, OEM
Certification: CE/FCC/RoHS/TUV/UL
Model Number: AOX-WDM12-R40
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: 10 or 20PCS /Plastic tray, 1PC/Gift box
Delivery Time: Within 1-3 working days after PO confirmed
Payment Terms: T/T, Western Union, L/C
Supply Ability: 50,000pcs/Month
Contact Now
Detailed Product Description
Product Name: 10G XFP Module Datarate: 10G/ps
Distance: 40KM Wavelength: TX 1270nm / RX 1330nm
DDM/DOM: YES Application: Datecom 10G Ethernet/ 10x FC Telcom OC192/STM-64
High Light:

cisco sfp modules

,

sfp transceiver



TX 1270nm 40KM BIDI WDM 10G XFP Module LC For Datacom 10G Ethernet


Specification:



P/N

AOX-WDM12-R40

Datarate

10G/ps

Wavelenth

TX 1270nm / RX 1330nm

Distance

40KM

Transmitter

DFB

Receiver

PIN

Media

SMF

DDM/DOM

YES

Connector

LC

Application

Datacom 10G Ethernet/ 2x 4x 8x FC

Operating Temperature

0℃~ +70℃

Voltage Supply

3.3V

Certification

CE/FCC/RoHS/TUV/UL

Brand

AscentOptics/Neuter, OEM



10G BIDI (WDM) XFP TX 1270nm/RX 1330nm 40KM Single-mode Datacom 10G Ethernet/ 2x 4x 8x FC


Description:



XFP modules are hot-swappable and protocol-independent. They typically operate at near-infrared wavelengths (colors) of 850 nm, 1310 nm or 1550 nm. Principal applications include 10 Gigabit Ethernet, 10 Gbit/s Fibre Channel, synchronous optical networking (SONET) at OC-192 rates, synchronous optical networking STM-64, 10 Gbit/s Optical Transport Network (OTN) OTU-2, and parallel optics links. They can operate over a single wavelength or use dense wavelength-division multiplexing techniques. They include digital diagnostics that provide management that were added to the SFF-8472 standard.  XFP modules use an LC fiber connector type to achieve high density.

The AscentOptics 10G XFP Module offers customers a variety of 10 Gigabit Ethernet and Packet-over-SONET/SDH (POS) connectivity options for data center, enterprise wiring closet, and service provider transport applications.

Features
  • 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-LR, single LC connector for bi-directional application, over 40km SMF
  • Electrical interface compliant to SFF-8431 specifications for enhanced 8.5 and 10 Gigabit small form factor pluggable module “XFP”
  • 1270/1330nm DFB transmitter, PIN photo-detector
  • 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface for optical transceivers
  • Part number(-40°C to 85°C):
  • line side, client side loopback function
  • Advanced firmware allow customer system encryption information to be stored in transceiver
  • ROHS compliant
  •

Applications



  • 10GE Ethernet switches and routers
  • 10GE Storage
  • SONET(OC-192)/SDH(STM64) line card

AscentOptics BIDI XFP

P/N Data Rate Distance Wavelength Media Connector
AOX-WDM13-R20 10G/ps 20KM 1330nm SM SC/LC
AOX-WDM12-R20 10G/ps 20KM 1270nm SM SC/LC
AOX-WDM13-R40 10G/ps 40KM 1330nm SM SC/LC
AOX-WDM12-R40 10G/ps 40KM 1270nm SM SC/LC




Competitive advantage:

1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
4. OEM/ODM  Customized label
5. Keep stock,Fast delivery
